Product : Inverter Microtek

UPS EB - 400

Battery : 1 Battery System
Input DC Range : 10.5 ∼ 14.2
Efficiency(on battery mode) : >84%
Protections
Overload : 110%
Short - Circuit : 300%
Charger Current : 6.5A
Warranty : 2 Years

Salient Features

MICROTEK UPS EB models are designed using latest state-of-the-art Technology for Better Performance & High Reliability.

  • MICRO-CONTROLLER BASED, Intelligent Control Design.
  • Display Indications (Status & Fault).
  • CCCV Technology with Auto Trickle Mode.
  • Smart Overload Sense and Short Circuit Protection.
  • Battery State Monitoring.
  • Easily Serviceable.
  • Multi Stage Battery Charger.
  • Mains Input Voltage Range Selection.
Technical Specifications
Input Voltage : 100V∼300V (Wide input voltage range) 180V∼260V (Normal input voltage range)
Output Voltage on Mains Mode : Same as Input
Output Voltage on UPS Mode : 200V∼230V ± 10%
Output frequency on UPS Mode : 50 Hz ± 0.1 Hz
Switching from Mains to UPS and from UPS to Mains : Automatic
Output Waveform on Mains Mode : Same as Input
Output Waveform on UPS Mode : TPZi Waveform (TRAPE ZOIDAL WAVEFORM)
Battery Charging Current : Constant Charging Approx 10% of The Rated Battery Current in AH
Charger : Constant Current, Constant Wattage
Efficiency : > 84%
UPS Overload : 120%
UPS Short Circuit : 300%
UPS Transfer Time : ≤ 15 msec.
Browns out Mains Voltage : 100V ± 40V
Technology : MICRO CONTROLLER BASED DESIGN
Auto Reset Feature : Yes


NOTE : Because of a policy of continuous product improvement, the specifications are subject to change without notice.



UPS EB - 600

Battery : 1 Battery System
Input DC Range : 10.5 ∼ 14.2
Efficiency(on battery mode) : >84%
Protections
Overload : 110%
Short - Circuit : 300%
Charger Current : 6.5A
Warranty : 2 Years

Salient Features

MICROTEK UPS EB models are designed using latest state-of-the-art Technology for Better Performance & High Reliability.



UPS EB - 860

Battery : 1 Battery System
Input DC Range : 10.5 ∼ 14.2
Efficiency(on battery mode) : >84%
Protections
Overload : 110%
Short - Circuit : 300%
Charger Current : 9A
Warranty : 2 Years

Salient Features

MICROTEK UPS EB models are designed using latest state-of-the-art Technology for Better Performance & High Reliability.


UPS EB - 1000

Battery : 1 Battery System
Input DC Range : 10.5 ∼ 14.2
Efficiency(on battery mode) : >84%
Protections
Overload : 110%
Short - Circuit : 300%
Charger Current : 12A
Warranty : 2 Years

Salient Features

MICROTEK UPS EB models are designed using latest state-of-the-art Technology for Better Performance & High Reliability.

  • MICRO-CONTROLLER BASED, Intelligent Control Design.
  • Display Indications (Status & Fault).
  • CCCV Technology with Auto Trickle Mode.
  • Smart Overload Sense and Short Circuit Protection.
  • Battery State Monitoring.
  • Easily Serviceable.
  • Multi Stage Battery Charger.
  • Mains Input Voltage Range Selection
Technical Specifications
Input Voltage : 100V∼300V (Wide input voltage range) 180V∼260V (Normal input voltage range)
Output Voltage on Mains Mode : Same as Input
Output Voltage on UPS Mode : 200V∼230V ± 10%
Output frequency on UPS Mode : 50 Hz ± 0.1 Hz
Switching from Mains to UPS and from UPS to Mains : Automatic
Output Waveform on Mains Mode : Same as Input
Output Waveform on UPS Mode : TPZi Waveform (TRAPE ZOIDAL WAVEFORM)
Battery Charging Current : Constant Charging Approx 10% of The Rated Battery Current in AH
Charger : Constant Current, Constant Wattage
Efficiency : > 84%
UPS Overload : 120%
UPS Short Circuit : 300%
UPS Transfer Time : ≤ 15 msec.
Browns out Mains Voltage : 100V ± 40V
Technology : MICRO CONTROLLER BASED DESIGN
Auto Reset Feature : Yes


NOTE : Because of a policy of continuous product improvement, the specifications are subject to change without notice.



UPS EB - 860

Battery : 1 Battery System
Input DC Range : 10.5 ∼ 14.2
Efficiency(on battery mode) : >84%
Protections
Overload : 110%
Short - Circuit : 300%
Charger Current : 6.5A
Warranty : 2 Years

Salient Features

MICROTEK UPS EB models are designed using latest state-of-the-art Technology for Better Performance & High Reliability.

  • MICRO-CONTROLLER BASED, Intelligent Control Design.
  • Display Indications (Status & Fault).
  • CCCV Technology with Auto Trickle Mode.
  • Smart Overload Sense and Short Circuit Protection.
  • Battery State Monitoring.
  • Easily Serviceable.
  • Multi Stage Battery Charger.
  • Mains Input Voltage Range Selection.
Technical Specifications
Input Voltage : 100V∼300V (Wide input voltage range) 180V∼260V (Normal input voltage range)
Output Voltage on Mains Mode : Same as Input
Output Voltage on UPS Mode : 200V∼230V ± 10%
Output frequency on UPS Mode : 50 Hz ± 0.1 Hz
Switching from Mains to UPS and from UPS to Mains : Automatic
Output Waveform on Mains Mode : Same as Input
Output Waveform on UPS Mode : TPZi Waveform (TRAPE ZOIDAL WAVEFORM)
Battery Charging Current : Constant Charging Approx 10% of The Rated Battery Current in AH
Charger : Constant Current, Constant Wattage
Efficiency : > 84%
UPS Overload : 120%
UPS Short Circuit : 300%
UPS Transfer Time : ≤ 15 msec.
Browns out Mains Voltage : 100V ± 40V
Technology : MICRO CONTROLLER BASED DESIGN
Auto Reset Feature : Yes


NOTE : Because of a policy of continuous product improvement, the specifications are subject to change without notice.



UPS EB - 1500

Battery : 2 Battery System
Input DC Range : 21 ∼ 28.4
Efficiency(on battery mode) : >84%
Protections
Overload : 110%
Short - Circuit : 300%
Charger Current : 9.5A
Warranty : 2 Years

Salient Features

MICROTEK UPS EB models are designed using latest state-of-the-art Technology for Better Performance & High Reliability.

  • MICRO-CONTROLLER BASED, Intelligent Control Design.
  • Display Indications (Status & Fault).
  • CCCV Technology with Auto Trickle Mode.
  • Smart Overload Sense and Short Circuit Protection.
  • Battery State Monitoring.
  • Easily Serviceable.
  • Multi Stage Battery Charger.
  • Mains Input Voltage Range Selection.
Technical Specifications
Input Voltage : 100V∼300V (Wide input voltage range) 180V∼260V (Normal input voltage range)
Output Voltage on Mains Mode : Same as Input
Output Voltage on UPS Mode : 200V∼230V ± 10%
Output frequency on UPS Mode : 50 Hz ± 0.1 Hz
Switching from Mains to UPS and from UPS to Mains : Automatic
Output Waveform on Mains Mode : Same as Input
Output Waveform on UPS Mode : TPZi Waveform (TRAPE ZOIDAL WAVEFORM)
Battery Charging Current : Constant Charging Approx 10% of The Rated Battery Current in AH
Charger : Constant Current, Constant Wattage
Efficiency : > 84%
UPS Overload : 120%
UPS Short Circuit : 300%
UPS Transfer Time : ≤ 15 msec.
Browns out Mains Voltage : 100V ± 40V
Technology : MICRO CONTROLLER BASED DESIGN
Auto Reset Feature : Yes


NOTE : Because of a policy of continuous product improvement, the specifications are subject to change without notice.



UPS EB - 2000

Battery : 2 Battery System
Input DC Range : 21 ∼ 28.4
Efficiency(on battery mode) : >84%
Protections
Overload : 110%
Short - Circuit : 300%
Charger Current : 12A
Warranty : 2 Years

Salient Features

MICROTEK UPS EB models are designed using latest state-of-the-art Technology for Better Performance & High Reliability.


Product : Microtek:

Enlarge view click Image
